Building a Search Engine From Scratch Part 1: The Inverted Index

How do you find a needle in 50,000 haystacks in a few milliseconds? You stop searching the haystacks and start searching a map of where the needles are.

Table of Contents

1. A Short History of Finding Things

2. Life After Google: Lucene, Elasticsearch and Algolia

3. What We Are Building in This Series

4. The Problem: Why Not Just Scan Everything?

5. The Big Idea: Forward Index vs. Inverted Index

6. Our Dataset (Briefly)

7. The Indexing Pipeline at a Glance

8. Step 1 Splitting the Corpus Into Documents

9. Step 2 Normalisation (Lowercasing)

10. Step 3 Tokenisation

11. Step 4 Stop Word Removal

12. Step 5 Stemming

13. Step 6 Recording Positions

14. Step 7 Building the Index Itself

15. A Complete Worked Example

16. The Mathematics of an Inverted Index

17. Step 8 Writing the Index to Disk

18. What Our Real Index Looks Like

19. Implementing This in Your Language of Choice

20. Engineering Notes, Trade-offs and Known Limitations

21. Recap and What's Next

22. References and Further Reading

1. A Short History of Finding Things

Every day, billions of people type a few words into a box and, in well under a second, get back a ranked list of relevant pages pulled from an index of an almost incomprehensible size. It feels like magic. It isn't. It is a handful of beautifully simple ideas, refined over decades, stacked on top of each other. This series is about rebuilding those ideas ourselves, one layer at a time.

But before we write a single line of logic, it is worth knowing where those ideas came from.

Before the Web: Archie (1990)

The first tool widely recognised as an Internet search engine was Archie, created in 1990 by Alan Emtage, then a student at McGill University in Montreal (with Bill Heelan and Peter Deutsch). Archie predates the World Wide Web. It periodically downloaded the file listings of public FTP servers and let you search those file names. It did not know what was inside the files only what they were called. Still, the core idea was already there: do the expensive work of collecting information ahead of time, so that answering a question later is cheap.

The Early Web: Directories and Crawlers (19941996)

When the Web exploded in the mid-1990s, two very different approaches emerged:

Full-text engines like AltaVista were technically impressive they could tell you which pages contained your words. The problem was ordering. If a page wanted to rank for "cheap flights", it could simply repeat "cheap flights" hundreds of times, sometimes in invisible text. Relevance based purely on a page's own content trusted the page to be honest about itself. Pages were not honest.

Stanford, BackRub and PageRank (19961998)

In 1996, Larry Page, a PhD student in computer science at Stanford University, started a research project to study the link structure of the Web. He was soon joined by fellow PhD student Sergey Brin. The project was part of the Stanford Digital Library Project, and it was nicknamed "BackRub" because its central object of study was backlinks the links pointing into a page.

The insight was borrowed from academia: a research paper is considered important if many other papers cite it, and especially if important papers cite it. Page and Brin applied the same reasoning to the Web: a link from page A to page B is a vote by A for B. Votes from pages that themselves receive many votes count for more.

That idea became PageRank. In the 1998 paper "The Anatomy of a Large-Scale Hypertextual Web Search Engine", Brin and Page wrote it as:

$$ PR(A) = (1 - d) + d \left( \frac{PR(T_1)}{C(T_1)} + \frac{PR(T_2)}{C(T_2)} + \dots + \frac{PR(T_n)}{C(T_n)} \right) $$

Where:

There's a lovely intuition behind it called the random surfer model: imagine someone clicking links at random forever, occasionally getting bored and jumping to a completely random page (that's the $1-d$ part). A page's PageRank is roughly the probability that this surfer is on it at any given moment. A page linked from many important pages gets visited a lot. A spam page that nobody links to does not no matter how many times it repeats "cheap flights".

The algorithm was formally described in the Stanford technical report "The PageRank Citation Ranking: Bringing Order to the Web" by Larry Page, Sergey Brin, Rajeev Motwani and Terry Winograd. Motwani and Winograd were Stanford faculty, and Hector Garcia-Molina, who led work in the Digital Library Project, was also a key academic mentor. Engineer Scott Hassan wrote much of the early code for the research prototype. Like most great systems, it was a team effort.

The research prototype was renamed Google a play on googol, the number $10^{100}$, signalling the ambition to organise an enormous amount of information. It ran at google.stanford.edu, and by the time the Anatomy paper was published, its database contained at least 24 million web pages.

In August 1998, Andy Bechtolsheim, co-founder of Sun Microsystems, saw a demo and wrote a $100,000 cheque to "Google Inc." a company that did not legally exist yet. Page and Brin incorporated it on September 4, 1998, working out of a rented garage in Menlo Park. The rest you know.

Photograph: Kim Kulish/Getty Images

The Part of the Story Most People Skip

Here is the detail that matters for us. PageRank decides the order of results. But before you can order anything, you need to find which of your 24 million pages contain the words "stanford university" at all and you need to do that in milliseconds.

If you read the Anatomy paper, a large portion of it is not about PageRank at all. It's about data structures: a lexicon of words, hit lists recording every occurrence of every word in every document (including the word's position), a forward index, and the star of today's post an inverted index, built by sorting the forward index by word.

PageRank made Google good. The inverted index made it possible.

2. Life After Google: Lucene, Elasticsearch and Algolia

Web search is the most visible kind of search, but it's far from the only one. Every time you search your email, filter products on an e-commerce site, look up a log line in a monitoring dashboard, or hit Ctrl+K on a documentation site, a search engine is running. Most of those search engines don't crawl the Web they index a company's own data. But underneath, they play the same game.

Apache Lucene (1999)

In 1999, Doug Cutting who had previously worked on search at Xerox PARC, Apple and Excite wrote Lucene, a full-text search library in Java, and released it as open source. (The name is his wife's middle name.) Lucene joined the Apache Software Foundation in 2001 and became a top-level Apache project in 2005. Cutting would later go on to co-create Nutch and Hadoop.

Lucene is not a server or a product it's the engine block. At its heart is, unsurprisingly, an inverted index, stored in immutable files called segments that are periodically merged together. Lucene powers an astonishing amount of the world's search, mostly indirectly, through the systems built on top of it: Apache Solr, Elasticsearch and OpenSearch.

Elasticsearch (2010)

Shay Banon started playing with an early version of Lucene while living in London, building a recipe search engine for his wife, who was attending culinary school. That experiment grew into an open-source project called Compass, which made Lucene easier to use from Java applications. Realising that the world needed something distributed and scalable, he rewrote it from scratch, and in 2010 released Elasticsearch: Lucene wrapped in a distributed server, spoken to over HTTP with JSON. Its company, now Elastic, built the well-known "ELK" stack (Elasticsearch, Logstash, Kibana). Every shard of an Elasticsearch cluster is you guessed it a Lucene index, which is an inverted index.

Algolia (2012)

Algolia was founded in 2012 in Paris by Nicolas Dessaigne and Julien Lemoine. They initially built an offline search engine SDK for mobile apps, where speed and tiny memory footprints were non-negotiable. The market for offline mobile search proved small, so around the time they went through Y Combinator (Winter 2014 batch) they pivoted to a hosted search-as-a-service API, bringing that obsession with speed and instant "search-as-you-type" relevance to websites and apps. Different business, different engine (they built their own rather than using Lucene), same foundational idea.

The Common Thread

Fifty years of progress in ranking, distribution, typo-tolerance and machine learning and the inverted index is still there, quietly doing the heavy lifting. That's what we're going to build today.

3. What We Are Building in This Series

By the end of this series you'll have built a working search engine from first principles. No search libraries, no databases, no magic.

A few ground rules for how this series is written:

• Language-agnostic. Our reference implementation is in Python, but this post contains no code snippets. Instead, we explain every step in terms of data structures, algorithms and a bit of maths, so you can implement it in Python, JavaScript, Go, Java, C#, Rust, C++ whatever you're comfortable with.

• Beginner-friendly. If you've never heard of a hash map, that's fine. We'll explain every structure as we meet it.

• Implementation-focused. We're here to understand how a search engine actually works inside. We'll keep document parsing deliberately simple for now and give it the attention it deserves in a later post.

4. The Problem: Why Not Just Scan Everything?

Our dataset is a single text file of about 270 MB containing 50,000 Wikipedia articles. Suppose a user searches for quantum.

The most obvious approach is: open the file, read every article from top to bottom, and collect the ones that contain the word "quantum". This is called a linear scan, and it's what a "find" feature in a text editor does.

It works. It's also terrible for a search engine:

Think about a printed textbook. If you want to find every page that mentions "photosynthesis", you don't read the book cover to cover. You flip to the index at the back, find "photosynthesis pages 45, 112, 230", and go straight there.

Someone did the hard work once, when the book was printed, so that every reader could find things instantly. That's precisely the trade an inverted index makes:

Spend a lot of time and memory up-front (indexing) so that every future question (query) is cheap.

5. The Big Idea: Forward Index vs. Inverted Index

The way documents naturally exist is as a mapping from document → words. This is called a forward index:

That's great if your question is "what words are in Doc 1?". But a search engine's question is the opposite: "which documents contain the word web?". To answer that with a forward index you'd have to check every row the linear scan again.

So we flip ("invert") the table, mapping word → documents:

That's an inverted index. Now answering "which documents contain web?" is a single lookup.

Some vocabulary we'll use from now on

Information retrieval has its own jargon. It's worth learning because you'll see it in every paper and every search engine's documentation.

Our index is a positional inverted index, meaning each posting stores not just which documents contain the term, but exactly where inside the document it appears. We'll see why that matters shortly.

6. Our Dataset (Briefly)

We use a single file, wikipedia_50000.txt (~270 MB), containing 50,000 English Wikipedia articles, already compiled together for simplicity. Each article is wrapped in simple XML-style tags:

That's all we need to know for now. Organising and parsing real-world documents (HTML, metadata, deduplication, fields, etc.) is a deep topic of its own and will get its own post later in the series. Today our parsing is intentionally minimal, so we can focus on the engine.

7. The Indexing Pipeline at a Glance

Here is the complete journey from raw text file to finished index. Every box is a section below.

Two functions in our reference implementation do all of this:

And an orchestrating main function reads the file, calls those two in order and writes the result to disk.

8. Step 1: Splitting the Corpus Into Documents

Our corpus is one giant string. We need to turn it into a list of documents.

What happens

1. Read the whole file into memory as a single string of text.

2. Lowercase everything (more on why in the next section).

3. Split the big string every time the closing tag </page> appears. Each resulting piece is (potentially) one article.

4. Remove the `<id>` tag *together with its value*. Wikipedia's page IDs (like 12) are essentially arbitrary numbers. Nobody searches for them and we don't use them anywhere, so we throw away the whole <id> ... </id> block instead of letting the number leak into the text as if it were a word.

5. Remove the remaining tags (<page>, <title>, </title>, <text>, </text>) by replacing each of them with nothing. The title and body text simply merge together into one stream of text.

6. Trim and filter. Strip leading and trailing whitespace from each piece, and keep it only if something is left. Empty pieces are discarded.

Why step 6? Splitting creates a piece for everything after each separator, including whatever comes after the very last </page>. Our file ends with a newline after the final </page>, so a naive split produces 50,001 pieces: 50,000 articles plus one piece containing nothing but whitespace. That ghost document would claim a document ID of its own and quietly inflate our document count, distorting any statistic that depends on $N$ (the number of documents) later in the series. Filtering out empty pieces guarantees exactly one list entry per real article.

The result is an ordered list (also called an array) of exactly 50,000 strings:

The data structure: a list (array)

A list is an ordered sequence of items stored one after another, where each item is reachable by its index its position in the sequence, counted from 0. Looking up item number i takes the same tiny amount of time no matter how long the list is. In computer science we write this as O(1) ("order one", or constant time).

Document IDs come for free

Notice something elegant: we don't need to invent IDs for our documents. A document's position in this list *is* its ID. The first article (Anarchism) is document 0, the next is document 1, and so on. Later, when the index tells us "the term appears in document 4,217", we can fetch that document instantly by going to index 4,217 of the list.

Why integers? Integers are small, cheap to compare and cheap to sort. Every real search engine maps documents to compact integer IDs internally, even if the documents have URLs or string keys externally.

Why our own IDs and not Wikipedia's? Wikipedia's page IDs are sparse and arbitrary (12, 39, ...). Our list positions are dense (0, 1, 2, ...), so a document ID can be used directly as an index into the list, with no extra lookup table.

9. Step 2: Normalisation (Lowercasing)

Computers compare text character by character, and to a computer "Google", "google" and "GOOGLE" are three completely different strings. A user searching for google would not find a document that only says Google.

So before anything else, we convert all text to lowercase. This is the simplest form of normalisation: transforming text so that things a human considers "the same word" actually look the same to the machine.

The golden rule of normalisation: whatever you do to the documents at indexing time, you must do to the query at search time. If we lowercase the documents but not the query, a search for Google would never match anything. We'll come back to this rule in Part 2.

Trade-off: lowercasing loses some information. "Apple" (the company) and "apple" (the fruit) become indistinguishable. Nearly every search engine accepts this trade, because it helps far more queries than it hurts.

10. Step 3: Tokenisation

Now we have documents as long strings of lowercase text. But we don't index strings, we index words. Tokenisation is the process of chopping a stream of text into individual units called tokens.

Our tokenisation rule

We use one simple, precise rule:

A token is any unbroken run of the characters `a``z` and `0``9`. Any other character (space, punctuation, hyphen, bracket, symbol, accented letter...) acts as a separator.

In regular-expression notation, this rule is written [a-z0-9]+, which reads as "one or more characters, each of which is in the range az or 09". Every programming language has a regular-expression engine that can find all matches of this pattern in a string, one after another. (If you'd rather not use regular expressions, you can implement the same rule by walking through the string one character at a time: keep appending characters to the current token while they're alphanumeric, and "close" the token whenever you hit any other character.)

Examples

Why such a simple rule?

Because it's predictable, fast and easy to replicate exactly at query time. Tokenisation is a surprisingly deep rabbit hole (think URLs, email addresses, "C++", "U.S.A.", Chinese text with no spaces at all...), and production engines like Lucene ship with many configurable tokenisers. For learning the core of a search engine, a simple rule applied consistently beats a clever rule applied inconsistently.

11. Step 4: Stop Word Removal

Some words are everywhere. "the", "of", "and", "is", "to" appear in virtually every English document. A list of documents containing "the" is essentially a list of all documents it tells us nothing useful, and it would be by far the largest entry in our index.

This is not a coincidence; it's a well-known statistical property of language called Zipf's law: in a large body of text, a word's frequency is roughly inversely proportional to its rank. The most common word appears about twice as often as the second most common, three times as often as the third, and so on. A tiny number of words account for a huge fraction of all the text.

Words that are extremely frequent but carry little meaning are called stop words, and we discard them before indexing.

Our stop word list

We use a small, hand-picked list of 40 common English words:

The data structure: a set

For every single token in all 50,000 documents (tens of millions of tokens), we have to ask: "is this a stop word?". If we stored the stop words in a plain list, answering that would mean comparing the token against each of the 40 words one by one. That's 40 comparisons, tens of millions of times.

Instead we store them in a set. A set is a collection of unique items that is optimised for one question: "is X in here?". Under the hood, most languages implement sets using hashing (explained properly in Step 7), which lets us answer the membership question in O(1) time on average roughly the same cost whether the set holds 40 words or 40,000.

The trade-off

Removing stop words makes the index smaller and faster. But it isn't free. The famous line "to be or not to be" consists entirely of words on our stop list after removal, nothing is left to search for! Modern web search engines often keep stop words for exactly this reason, and handle their cost with smarter techniques. For our engine, removing them is the right call: it's simpler and keeps our index lean.

12. Step 5: Stemming

Consider a user searching for connection. Should a document that says "connected" match? What about "connecting"? Almost certainly yes they're all about the same idea. But to a computer, they're different strings.

Stemming is the process of chopping words down to a common root form, called a stem, by stripping suffixes like -ing, -ed, -s, -ion, -ism, and so on.

The algorithm we use

The classic stemming algorithm is the Porter stemmer, published by Martin Porter in 1980. It's a sequence of carefully ordered rules, applied in steps, of the form "if the word ends in X, and what's left meets condition Y, replace X with Z".

Our implementation uses the Snowball English stemmer (via the PyStemmer library), commonly known as "Porter2" Martin Porter's own improved revision of his original algorithm. Snowball stemmers are available for practically every language, so whatever language you implement this in, you can find a compatible English Snowball/Porter2 stemmer, or implement it yourself from the published rules.

Real examples from our stemmer

These are actual outputs from the stemmer used in our implementation:

Things worth noticing

1. Stems don't have to be real words. engin, polit and philosophi aren't English. That's fine users never see stems. They only need to be consistent: every form of "engine" produces engin, both in documents and in queries.

2. Stemming is rule-based, not "intelligent". It doesn't know that "ran" is the past tense of "run". Reducing words to their dictionary form using actual linguistic knowledge is called lemmatisation, and it's slower and more complex.

3. There are two kinds of mistakes. Over-stemming merges words that shouldn't be merged; under-stemming fails to merge words that should be (like anarch vs. anarchist above). Every stemmer is a balance between the two.

After stemming, our token has become a term the unit that actually goes into the index.

13. Step 6: Recording Positions

We could stop here and build an index that only records which documents contain each term. That would be enough for queries like "find documents containing stanford and university". But it can't tell the difference between:

• "...he attended Stanford University in California..."

• "...the university sent a delegation to the Stanford linear accelerator..."

Both contain both words. Only the first contains the phrase "stanford university". To support phrase queries, we need to know where in each document each term appears. So for every term we keep, we record its position.

How positions are counted

We keep a counter for each document, starting at 0. Every time we keep a token (i.e. it's not a stop word), we record the counter's current value as that token's position, then add 1 to the counter.

Crucially: stop words do not advance the counter. Positions count meaningful terms only.

Let's see what that means on the sentence "The University of Stanford is in California":

Because "of" was skipped, universiti (position 0) and stanford (position 1) are now adjacent. A query for "university of stanford" goes through the same pipeline at search time, becomes universiti stanford, and can be matched by checking for consecutive positions. This is a deliberate and very practical design choice and it's exactly the kind of consistency that makes Part 2 work.

This idea isn't new, by the way. The original Google prototype stored "hit lists" for every word in every document, and each hit recorded the word's position (along with things like font size and capitalisation).

14. Step 7: Building the Index Itself

Now for the main event. We have a stream of (term, docId, position) facts coming out of the pipeline. We need to organise them so that, given a term, we can instantly get every document and position where it appears.

The data structure: a hash map

A hash map (also called a hash table, dictionary, map or associative array depending on your language) stores key → value pairs and lets you find the value for a given key in O(1) time on average.

Here's how it works, conceptually:

1. The map holds an internal array of "buckets".

2. When you store a key, a hash function turns the key (e.g. the string "search") into a big number.

3. That number, reduced to the size of the array (using the remainder after division, modulo), tells the map which bucket to put the pair in.

4. To look up a key later, the map computes the same hash, jumps straight to that bucket, and finds the pair without looking at any other buckets.

Two different keys occasionally land in the same bucket (a collision); hash maps handle that internally, so on average a lookup still costs roughly the same regardless of whether the map holds 10 keys or 548,800. That's exactly what we need for a vocabulary of over half a million terms.

The shape of our index

Our inverted index is a hash map of lists of pairs:

• Key: a term (string), e.g. "web"

• Value: a postings list a list of postings, sorted by docId

• Posting: a pair of (docId, list of positions), positions sorted ascending

Written out, the entry for web in our small example looks like this:

"web"  →  [ (0, [3]),  (1, [0, 1]) ]
            │   │       │   └── positions inside doc 1
            │   │       └────── docId 1
            │   └────────────── positions inside doc 0
            └────────────────── docId 0

Or as a nested structure diagram:

The insertion algorithm

For every kept term at position pos in document docId, we do the following:

1. Is this term new? Look it up in the hash map. If it isn't there, create an entry for it with an empty postings list.

2. Is this the first time we've seen this term *in this document*? Look at the last posting in the term's postings list:

- If the list is empty, or the last posting belongs to a different document → append a new posting (docId, [pos]). - Otherwise (the last posting is for the current document) → simply append `pos` to that posting's positions list.

1. Advance the position counter by one.

The clever bit: why only check the last posting?

This is the most important engineering insight in the whole indexer, so let's slow down.

We process documents in order: all of document 0, then all of document 1, then document 2, and so on. That means:

• Any posting for the current document can only have been created during the current document's processing, so if it exists, it must be the last one in the list.

• Every posting in the list belongs to a document we've already finished or the one we're on so docIds in each postings list are automatically in increasing order.

• Within a document, positions are handed out in increasing order, so each positions list is also automatically sorted.

So with a single O(1) check of the last element, we get two big wins:

This is a single-pass algorithm: we read every token exactly once, and when we're done, the index is complete and sorted.

15. A Complete Worked Example

Let's trace the whole pipeline by hand on a tiny corpus of three documents. Do this once with pen and paper and you'll understand inverted indexes better than most people who use them every day.

The corpus

Steps 2-6: for every document

Document 0: search engines index the web

Document 1: the web is a web of pages

Document 2: indexing pages makes searching fast

Step 7: watching the index grow

After document 0 four new terms, each gets its first posting:

After document 1 the first web (position 0): the last posting of web is for doc 0 ≠ doc 1, so we append a new posting. The second web (position 1): the last posting is now for doc 1 = current doc, so we just add the position. page is new.

After document 2 index, page and search already exist, so each gets a new posting for doc 2. make and fast are new.

Using what we built (a sneak peek)

• "Which documents mention searching?" → normalise and stem the query to search → look it up → docs 0 and 2. Notice that doc 2 matched even though it says "searching", not "search". That's stemming paying off.

• "Which documents contain both index and page?" → index is in {0, 2}, page is in {1, 2} → the intersection is doc 2.

• "Which documents contain the phrase index pages?" → in doc 2, index is at position 0 and page is at position 1 consecutive. Match.

We'll implement all of this properly in Part 2.

16. The Mathematics of an Inverted Index

You don't need maths to build an index, but describing it formally makes the design crystal clear, and the quantities we define here are the building blocks of ranking later in the series.

Definitions

Let:

• $D = \{d_0, d_1, \dots, d_{N-1}\}$ be the collection of $N$ documents, where each $d_j$ is identified by the integer $j$.

• Each document, after the pipeline (tokenise → remove stop words → stem), becomes a sequence of terms: $d_j = (t_{j,0},\ t_{j,1},\ \dots,\ t_{j,L_j - 1})$, where $L_j$ is the number of kept terms in document $j$.

• $V$ (the vocabulary) be the set of all distinct terms across all documents.

Then the positional inverted index is a function that maps every term to its occurrences:

$$ I : V \rightarrow \text{postings} $$

$$

I(t) = \Big[\, \big(j,\ P_{t,j}\big) \ \Big|\ P_{t,j} \neq \varnothing \,\Big] \quad \text{sorted by } j

$$

where the position set of term $t$ in document $j$ is:

$$ P_{t,j} = \{\, p \mid t_{j,p} = t \,\} $$

In words: "the positions $p$ in document $j$ where the term at position $p$ is $t$". The postings list for $t$ contains one entry for every document where that set is not empty.

Useful quantities you get for free

Keep an eye on $tf$ and $df$. Intuitively, a term that appears often in a document (high $tf$) but in few documents overall (low $df$) is a strong signal of what that document is about. That intuition is the basis of classic relevance scoring, and our index already contains everything needed to compute it.

Invariants (things that are always true)

A good engineer states the guarantees their data structure provides. Ours guarantees:

1. Postings are sorted by docId: in every $I(t)$, docIds strictly increase. (Because we process documents in order.)

2. Positions are sorted: every $P_{t,j}$ is in strictly increasing order. (Because the position counter only goes up.)

3. No duplicate documents: each docId appears at most once in a postings list. (Because of the "check the last posting" rule.)

4. Positions are dense over kept terms: in each document, the positions $0, 1, \dots, L_j - 1$ are each used by exactly one term. (Because stop words don't advance the counter.)

Complexity

Let $T$ be the total number of tokens in the corpus (before stop word removal).

The space formula reveals an important truth: a positional index stores roughly one number for every meaningful word in the corpus. That's why positional indexes are big as we'll see in a moment.

17. Step 8: Writing the Index to Disk

So far, the index lives in memory (RAM). The moment the program exits, it's gone. Building it takes a while, so we don't want to rebuild it every time someone wants to search. We serialise it convert it into a flat text format and save it to a file called invertedIndex.txt. The query program (Part 2) will load it back.

The file format

One line per term, in this shape:

term|docId:pos,pos,pos;docId:pos,pos;docId:pos

Our worked example would be written as:

search|0:0;2:3
engin|0:1
index|0:2;2:0
web|0:3;1:0,1
page|1:2;2:1
make|2:2
fast|2:4

Why this format is safe

Here's a subtle point that's easy to miss. Using |, ;, : and , as delimiters only works if none of those characters can ever appear inside a term or a number. Normally you'd have to worry about "escaping" them. But remember our tokenisation rule: terms are made only of az and 09. Our tokeniser already guarantees that delimiters never appear in terms, so the format can be read back unambiguously by simply splitting on each delimiter in turn. Earlier design decisions making later ones simpler that's good engineering.

Reading it back (preview)

To reconstruct the index in memory, for each line: split once on | to get the term and the postings text; split the postings text on ; to get each posting; split each posting on : to get the docId and the positions text; split the positions text on , and convert each piece to an integer. We'll do exactly this in Part 2.

18. What Our Real Index Looks Like

Running the indexer on our full dataset of 50,000 Wikipedia articles produces:

Yes the index is about three-quarters the size of the original text. That's the cost of storing a position for every meaningful word, written out as human-readable digits. (Real engines compress this heavily; see the next section.)

Some real terms from our index

Notice how wildly $df$ varies from thousands of documents down to just two. Rare terms are the most discriminating: searching for lucen immediately narrows 50,000 documents down to 2.

Zooming in on document 0

Document 0 is the Wikipedia article on Anarchism. After Step 1 (the <id> block removed, tags stripped, text lowercased), it starts like this:

anarchism anarchism is a political philosophy and movement that is skeptical ...

Following the pipeline:

And here are the actual first lines of our generated invertedIndex.txt (truncated):

anarch|0:0,1,22,36,80,130,202,223,275,294,...
polit|0:2,40,281,784,808,941,965,1066,...
philosophi|0:3,323,1625,1654,2083,3029,4153;4:3687;5:7619;...
movement|0:4,34,47,92,138,153,395,604,608,...
skeptic|0:5;5:8165;30:2111;77:3627,3652;78:272;...

It matches our hand trace exactly. The title and the first word of the body both become anarch at positions 0 and 1, polit lands at position 2, and so on. The terms appear in the file in the order they were first discovered, because that's the order they were inserted into the hash map.

Why removing the IDs mattered: before we dropped the <id> block, every article's Wikipedia ID became a "word" at position 0. Removing the IDs shrank the vocabulary from 548,800 to 500,824 terms, which means about 48,000 terms existed only because of page IDs. Numbers that genuinely appear in article text (for example 12, which still appears in 8,689 documents) are still indexed, just as they should be.

19. Implementing This in Your Language of Choice

Everything in this post maps onto standard data structures found in every mainstream language:

Your checklist

If you implement this yourself, your indexer is correct when:

• [ ] Documents are numbered 0 … N-1 in the order they appear, with exactly one entry per real article (no empty pieces).

• [ ] The <id> block is removed entirely, so page IDs never appear as terms.

• [ ] All text is lowercased before tokenising.

• [ ] Tokens are maximal runs of az09; everything else separates.

• [ ] Stop words are dropped and do not advance the position counter.

• [ ] Every kept token is stemmed with an English Snowball (Porter2) stemmer.

• [ ] Each postings list is sorted by docId, each positions list is sorted, with no duplicate docIds.

• [ ] The output file uses term|docId:pos,pos;docId:pos with one term per line.

• [ ] Running it on the worked example in Section 15 produces exactly the table shown there.

That last item is your unit test. Always test on something small enough to check by hand before you trust a result on 50,000 documents.

20. Engineering Notes, Trade-offs and Known Limitations

Our indexer is deliberately simple, so it's honest to point out where a production system would do things differently. None of these matter for learning, but all of them matter at scale.

A taste of compression

Look at a positions list like 0:0,1,22,36,80,130,202. Instead of storing each position, we could store the first one as-is and then only the gaps between consecutive positions: 0, 1, 21, 14, 44, 50, 72. The same trick works for docIds in postings lists. Because lists are sorted (thank you, invariants!), gaps are always positive and usually small, and small numbers can be stored in fewer bytes using variable-length integer encodings. This is how real engines shrink positional indexes dramatically. Notice how sortedness, which we got for free in Step 7, keeps paying dividends.

A remaining simplification

• Titles and bodies are merged. A word in the title is treated exactly like a word in the body. In a real engine, a match in the title is usually a much stronger signal, so fields are indexed separately.

That's a parsing concern, and it's exactly why parsing gets its own post later in this series. (The two other parsing pitfalls we hit, Wikipedia IDs leaking into the text and the ghost empty document created by splitting, are already handled in Step 1.)

21. Recap and What's Next

We've covered a lot of ground. Let's zoom out:

What you now know:

1. Why search engines don't scan documents at query time, and how the inverted index trades indexing-time work for query-time speed the same idea that sat at the core of Google's original 1998 architecture and still sits at the heart of Lucene, Elasticsearch and Algolia.

2. How text becomes terms: lowercasing, tokenising, removing stop words and stemming and the golden rule that queries must go through the exact same pipeline.

3. Why positions matter, and why skipping stop words when counting positions is a deliberate design choice.

4. How the index is structured: a hash map from terms to postings lists of (docId, positions) pairs.

5. The single-pass trick: checking only the last posting gives O(1) insertions and sorted postings for free.

6. The maths: $tf$, $df$, $cf$, the invariants our index guarantees, and its time and space complexity.

7. How to persist the index in a simple, unambiguous text format.

We now have a ~206 MB file that knows where each of 500,824 terms appears across 50,000 Wikipedia articles. But an index nobody can query is just an expensive text file.

In the next post, we'll put it to work: querying the inverted index we've just built. We'll load it back into memory, run every query through the same pipeline we built today, and implement three kinds of search on top of it one-word queries, free-text queries, and phrase queries that use those positions to find exact sequences of words. That's where the sorted postings lists and dense positions we were so careful about today really pay off.

See you in Part 2. 🔍

22. References and Further Reading

• Sergey Brin and Lawrence Page, "The Anatomy of a Large-Scale Hypertextual Web Search Engine", Computer Networks and ISDN Systems, Vol. 30, 1998. Available from Stanford's InfoLab.

• Lawrence Page, Sergey Brin, Rajeev Motwani and Terry Winograd, "The PageRank Citation Ranking: Bringing Order to the Web", Stanford InfoLab Technical Report, 1998/1999.

• Christopher D. Manning, Prabhakar Raghavan and Hinrich Schütze, Introduction to Information Retrieval, Cambridge University Press, 2008 (free online). Chapters 1, 2 and 4 cover inverted indexes, tokenisation, stemming and index construction in depth.

• Martin F. Porter, "An algorithm for suffix stripping", Program, Vol. 14, No. 3, 1980.

• The Snowball project (snowballstem.org), home of the Porter2 / English Snowball stemmer.

• Apache Lucene project documentation (lucene.apache.org).

• Elastic, "Elasticsearch: The Definitive Guide" and the history of Compass and Elasticsearch by Shay Banon.

• Algolia's company story on algolia.com.
